FUFL Seeders

MPBC’s Femtosecond Ultrafast Fiber Laser Seeders are entirely fiber-based femtosecond lasers with exceptional laser pulse and beam qualities.

They deliver femtosecond pulses through polarization-maintaining fiber, eliminating the need for bulky optics.

These Seeders exhibit outstanding stability in diverse environmental conditions and need no maintenance.

The Seeder pulses can be stretched using specialized FBG stretchers, amplified for increased power, and subsequently compressed to achieve femtosecond duration, making them ideal for applications, such as science, multi-photon research and quantum technology.

  • All-fiber design with no bulk optics
  • Femtosecond pulses delivered in PM fiber
  • Extremely extended laser lifespan
  • Superior beam quality
  • Low amplitude and phase noise
  • Compact size
  • Figure-8 technology
FUFL Seeders

Principales caractéristiques

01

All-Fiber design with no bulk optics

The femtosecond laser utilizes an all-fiber design with no bulk optics, ensuring enhanced stability and compactness

FUFL Seeders

02

Femtosecond Pulses delivered in PM fiber

Delivering femtosecond pulses in fibers, rather than free space, simplifies light delivery and provides superior alignment stability.

03

Extended laser lifetime

The laser's design contributes to its extremely extended lifespan, ensuring reliable and cost-effective long-term operation

04

Low Amplitude and Phase Noise

The fiber laser design ensures low amplitude and phase noise, resulting in superior stability and performance

Longueurs d'onde disponibles

Spécifications optiques

Custom Table
Central Wavelength 1030 nm 1560 nm 1850 to 2100 nm
Spectral Width 3 nm >3 nm >15 nm
Repetition Rate 10-25 MHz 10-80 MHz 10-80 MHz
Pulse Duration 600-800 fs 80-800 fs 80-800 fs
Average Power 3 to 10 mW 1 to 50 mW 1 to 50 mW

*Optional: FBG fiber stretchers can be requested to stretch pulses to hundreds of picoseconds while matching the higher-order dispersion of your compressor gratings

Mechanical Specs

Custom Table
FUFL-SE FUFL-SH FUFL-S2
Dimensions (L x W x H) 200 x 130 x 28.5 mm 227 x 170 x 37 mm 248 x 436 x 83 mm
275 x 436 x 93 mm*
Power Supply 5 V 12 V Built-in
Cooling Method** Thermal Plate Thermal Plate Air Cooled

*With fans and legs
** Supplied by customer

Spécifications sujettes à changement sans préavis
